Product Details:
|
|
| Place of Origin: | Shanghai, China |
|---|---|
| Brand Name: | NL |
| Certification: | FDA |
| Model Number: | UCSD |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 61 Meter/Meters (Min. Order) |
| Price: | $18.00 - $49.00 / Meter |
| Packaging Details: | Standard packing. If you have any special requirement, please tell us in time. |
| Delivery Time: | Quantity(Meters) 1 - 61 Est. Time(days) 10 |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 10000 Meter/Meters per Week |
|
Detail Information |
|||
| Size: | 3/4"~4" | Length: | 61m/roll |
|---|---|---|---|
| Thickness: | 6.5~10mm | Material: | Conductive Black UHMWPE |
| Temp. Range: | -40℃~+ 120℃ | Processing Service: | Moulding, Cutting |
| Color: | Blue\Black | ||
| Highlight: | 200psi UPE Flexible Chemical Hose,50.8mm Flexible Chemical Hose,50.8mm 2 Inch Chemical Hose |
||
Product Description
| Part no. | ID | OD | Bending radius | Work pressure | Length | ||
| inch | mm | mm | mm | psi | bar | m | |
| UCSD019 | 3/4" | 19.05 | 32.0 | 89 | 200 | 13.8 | 61 |
| UCSD025 | 1" | 25.4 | 37.3 | 100 | 200 | 13.8 | 61 |
| UCSD032 | 1-1/4" | 31.8 | 45.0 | 130 | 200 | 13.8 | 61 |
| UCSD038 | 1-1/2" | 38.1 | 52.0 | 154 | 200 | 13.8 | 61 |
| UCSD051 | 2" | 50.8 | 66.3 | 208 | 200 | 13.8 | 61 |
| UCSD063 | 2-1/2" | 63.5 | 76.1 | 252 | 200 | 13.8 | 61 |
| UCSD076 | 3" | 76.2 | 96.2 | 305 | 200 | 13.8 | 61 |
| UCSD102 | 4" | 101.6 | 120.6 | 407 | 200 | 13.8 | 61 |
Packaging & Shipping
FAQ
1. Are you manufacture?
We started business from trading, but now we have invested and holded several factory in china.
2. Can you ship to my country?
We can ship to all the countries around the world by air or sea.
3. How much is the shipping charge to my country?
It depends on your country located and the weight of goods.
4. What's the price term?
EXW, FOB, CIF, CFR
5. What's your payment?
T/T, L/C, Western Union
